Power Source

The module is powered either directly from the Panel System or from an external source.

Operation of the Ei413

On receiving a volt-free switched hardwired signal from the panel, the module will transmit a RadioLINK alarm signal to activate the alarms in the system.

If a fire alarm has activated, the module will recognise the signal as a fire, and switch the relevant contacts to activate the panel.

If a Carbon Monoxide alarm has activated, the module will recognise the signal as a Carbon Monoxide leak and switch the relevant contacts to activate the panel.

Panel Activation

The module will decode a ‘Fire’, ‘Carbon Monoxide’ and fault signals from RadioLINK devices and activate the Panel accordingly and will also work the other way, activating the domestic alarms if it receives a signal from the Panel.

Features:

• Creates a two-way communication between Aico alarms and a panel system
• Connects wirelessly with all other Aico wireless interconnection products and is hard wired into the Panel system
• Powered directly from the Panel system
