Proprietary wireless communication technology to transmit commands, alarms, and events.

Key features:

• Two-way communication.
• Advanced anti-sabotage.
• Block encryption featuring a dynamic key.
• Instant notifications.
• Remote control and configuration in Ajax apps.

866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz

Depends on the sales region.

up to 20 mW

Automatic power control to reduce power consumption and radio interference.

up to 1,700 m

Between the range extender and a hub in an open space.

All stored and transmitted data are protected by block encryption featuring a dynamic key.

To prevent radio interference and jamming.

Proprietary wireless communication technology for uploading firmware updates.

Key features:

• Two-way communication.
• Advanced anti-sabotage.
• Block encryption featuring a dynamic key.
• Data packages reload in case of transmission errors.

866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz

Depends on the sales region.

up to 1,700 m

Between the detector and a hub (or a range extender) in an open space.

All stored and transmitted data are protected by block encryption featuring a dynamic key.

To prevent radio interference and jamming.

2 × PIR sensors

1 × K-band microwave sensor

K-band microwave sensor to prevent false alarms caused by thermal interference.
Operation frequency: 24 GHz.

up to 15 m

When installed at a height of 2–4 m.

Depends on the sensitivity level adjusted in the device settings.

horizontal: 7°

vertical: 73°

horizontal: 43°

vertical: 88°

To catch an intruder on photos, the device can start taking photos when a threat is detected in the pre-alarm detection zone. However, the device does not raise an alarm if the intruder never crosses the main detection zone.

from 0.3 to 2.0 m/s

The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility.

3 levels

Adjusted by a PRO or a user with admin rights in Ajax apps.

Dual motion detection technology

SmartDetect

Software algorithm.

A built-in camera is activated if the detector is armed and motion is detected.

User takes pictures at any time or when the detector is armed (depends on settings). The feature is disabled by default.

A detector camera takes pictures automatically when Ajax fire detectors are triggered. The feature is disabled by default.

The detector automatically takes photos at a specified time. This feature is available for hubs with firmware version OS Malevich 2.19 or higher.

The detector automatically takes photos when the security state is changed.

640 × 480 px

320 × 240 px (default)

Adjusted by a PRO or a user with admin rights in Ajax apps.

horizontal: 121°

vertical: 92.5°

To take photos in low-light conditions.

from 1 to 5 images with a resolution of 320 × 240 px

from 1 to 3 images with a resolution of 640 × 480 px

Adjusted by a PRO or a user with admin rights in Ajax apps.

up to 9 s for 320 × 240 px resolution

up to 20 s for 640 × 480 px resolution

Photo delivery time depends on the image resolution selected in the device settings.

Notifications on attempts to detach the detector from the surface or remove it from the mounting panel.

detects attempts to tilt or shift the detector or detach it from the surface

detects attempts to block the detector view

secures the device to SmartBracket

after 36 s

Detection time depends on the Jeweller or Jeweller/Fibra settings.

6× CR123A

Pre-installed.

12−24 V⎓

The batteries serve as a backup when an external power supply is connected.

234 × 98 × 275 mm

234 × 98 × 137 mm

1,109 g

620 g

from −25 °C to +60 °C

CurtainCam Outdoor HighMount (PhOD) Jeweller

6 × CR123A battery (pre-installed)

SmartBracket mounting panel

Swivel mount

Hood

Installation kit

Quick start guide
