C-TEC CAST 4-Way Conventional Zone to CAST Addressable Zone Converter
CAST 4-Way Conventional Zone to CAST Addressable Zone Converter
DELIVERY
We always aim to same day dispatch on all orders received before 2.30pm.
TRADE COUNTER
Firesense also offer the ability to collect your order from our trade counter.
Facilitates the conversion and upgrade of a multi-zone conventional fire alarm system to an addressable CAST system utilising the conventional system’s pre-existing zonal wiring.
Features
- Four individual zonal circuits accommodate CAST addressable devices on separate isolated circuits.
- Supplied as a 4 zone loop powered unit, extendable to 8 zones using a CA740PCB extender PCB (the extra PCB is housed in the same enclosure but is allocated a separate loop address by the CIE).
- Fully complies with the requirements of BS 5839-1 and eliminates the need to provide extra wiring to extend loops while maintaining loop and individual zone circuit integrity
- Ideal for use on retrofit sites such as nursing homes where conventional devices are being replaced in situ with addressable devices and the existing wiring needs to be retained.
- Maintains loop and individual zone circuit integrity.
- Plastic enclosure provides ample space to connect loop and zone cabling.
- No end-of-line devices, PSU or batteries required.
| Category Type | Interface |
|---|---|
| Colour | Grey |
| IP Rating | IP30 |
| System Type | Addressable |
| Clearance | No |
Write Your Own Review
| Compatibility | Compatible with C-TEC's XFP/ZFP CAST Addressable Fire panels. Compatible with CAST and CAST-PRO Devices |
| Application/Operation | Facilitates the upgrade of a multi-zone conventional fire alarm system to an addressable CAST system utilising the pre-existing wiring. |
| Supply/operating voltage | 22V to 40V DC |
| Quiescent current | (0mA Active), 1.4mA |
| Indicators | Zones 1-4 & 5-8 Polling LEDs (Red), Zone 1-4 & 5-8 Isolator Open LEDs (Yellow) |
| Dimensions | 380 W x 235 H x 96 D. Can be surface or flush mounted |
| Construction & Finish | Plastic Lid and Base |
| IP Rating | IP30 |
| Weight | 1.5kg approx (without batteries) |
| Operating Conditions/temperature | -10°C to +55°C |
| Notes | Max cable length per zone <500m; Mac 20 CAST or CAST-PRO devices per zone. The CA740 takes a loop address and is assigned as a CAST I/O at programming |
