In stock
Product Code
EXP-003-065
SKU
AD8852PW
Advanced ExGo Hold Switch, IP65 Enclosure
Hold Switch, IP65 Enclosure
DELIVERY
We always aim to same day dispatch on all orders received before 2.30pm.
TRADE COUNTER
Firesense also offer the ability to collect your order from our trade counter.
The Hold and Abort Switch Modules complement the ExGo extinguishing and suppression control panels. The modules comply with the requirements of BS7273-1. The switches are easy to wire and multiple units can easily be daisy-chained together on an input circuit. A range of finishes are available - white, stainless steel and brass trims. Alternatively, the unit can be supplied in an IP65 rated enclosure. The standard units can be surface mounted or semi-flush mounted onto standard 3½” electrical boxes. The IP65 unit is surface mounted. All units are provided with an end of line resistor (Reol). Compatible with the ExGo gas extinguishing panel and remote status indicator panel input circuits.
The Hold and Abort Switch Modules complement the ExGo extinguishing and suppression control panels. The modules comply with the requirements of BS7273-1. The switches are easy to wire and multiple units can easily be daisy-chained together on an input circuit. A range of finishes are available - white, stainless steel and brass trims. Alternatively, the unit can be supplied in an IP65 rated enclosure.
The standard units can be surface mounted or semi-flush mounted onto standard 3½” electrical boxes. The IP65 unit is surface mounted. All units are provided with an end of line resistor (Reol). Compatible with the ExGo gas extinguishing panel and remote
status indicator panel input circuits.
Features
- Range of finishes available
- Surface or flush mount
- IP65 option
- Complies with BS7273-1 requirements
- Standard units available in white plastic finish
| Category Type | Hold Switch |
|---|---|
| IP Rating | IP65 |
| System Type | Extinguishant |
| Clearance | No |
Write Your Own Review
| Dimensions (Plastic Unit) | Overall 87mm x 87mm x 41mm, Back box 87mm x 87mm x 29mm |
| Dimensions (Metal Trim Unit) | Overall 87mm x 87mm 47mm, Back box 87mm x 87mm x 44mm |
| Minimum depth behind cover | 35mm |
| Dimensions (IP65 Unit) | Overall 72 x 72 x 62 (including switch actuator) |
| Environmental Class | Indoor 0ºC to 40ºC |
| Humidity | 95% max |
| End-of-Line Resistance | 6800 Ohms |
| SW#1 Active Resistance | 470 Ohms |
| Maximum Operating Voltage | 30VDC |
