In stock
Product Code
BF320JP
SKU
CT1006NJS
C-TEC Single Gang Locking Jack Socket for BF320
Single Gang Locking Jack Socket for BF320
DELIVERY
We always aim to same day dispatch on all orders received before 2.30pm.
TRADE COUNTER
Firesense also offer the ability to collect your order from our trade counter.
Can be used in conjunction with a BF320 vibrating pillow pad to warn the hearing impaired of a potential fire alarm or evacuation alert condition.
Features
- Compatible with all C-TEC fire alarm and evacuation alert systems.
- Locking mini-XLR connector and plug arrangement helps prevent accidental pillow pad removal.
- Line monitored for disconnection via an internal 6k8Ω end of line resistor (selectable at the BF320JP).
- Selectable 6K8 (pillow pad) or 27K (jack socket) end of line monitoring options for fire alarm or evacuation alert system use.
- Can be used on systems with a 10-30V DC voltage range
- Fits on a standard UK 25mm back box.
- Supersedes C-TEC's old BF364 jack socket.
| Category Type | Accessory |
|---|---|
| Colour | Grey |
| System Type | Conventional |
| Clearance | No |
Write Your Own Review
| Compatibility | Designed for use with C-TEC's BF320 Vibrating Pillow Pad |
| Application/Operation | Connects across a conventional fire alarm system's 24V DC sounder circuit or across the circuits of a CA737 Four Way Flat Interface Unit on a C-TEC Evacuation Alert System |
| Supply/Operating voltage | 10-30V |
| Alarm Current | 65mA at 24V, 110mA 10V (when pressure pad connected) |
| Connections | +24V and 0V |
| Product Dimensions (mm) | 86W x 86 H x 15 D. Can be mounted on a standard UK 25mm single gang flush or surface back box |
| Construction & Finish | PVC White RAL90003. Grey/blue label |
| Weight | 56g |
| Operating conditions/temperature | -10°C to +60°C |
| Notes | On a C-TEC Evac-Alert System, power for the BF320JP should be derived from a mains powered CA737 Four Way Flat Interface Unit. See instruction for end of line monitoring options |
