In stock
Product Code
149623.263.BL1
SKU
149623.263.BL1
Ajax Hub BP Jeweller (8EU/UEU) ASP - Black
Wireless battery-powered control panel. Supports photo verification. Connectable via two SIM cards (2G/3G/LTE)
DELIVERY
We always aim to same day dispatch on all orders received before 2.30pm.
TRADE COUNTER
Firesense also offer the ability to collect your order from our trade counter.
Battery-powered Ajax hub for remote or off-grid sites. It keeps the security system online where mains power is unavailable or unreliable, with cellular communication and power-saving operation. It gives the installer a central platform that can be configured, tested and adjusted through the Ajax app ecosystem, helping reduce time spent on setup and ongoing maintenance.
Key features:
- Designed for sites without stable mains power
- Dual SIM
- External antenna support
- Long operating time with suitable external batteries
- Jeweller wireless communication
- App-based setup and administration
- Remote configuration through Ajax apps
- Alarm transmission to users and monitoring stations
- Encrypted communication with connected Ajax devices
- Battery-focused operation for sites without stable mains
| Approval | Grade 2 (EN 50131), PD 6662:2017 |
|---|---|
| Category Type | Hubs |
| Colour | Black |
| IP Rating | IP40 |
| System Type | Intruder |
| Clearance | No |
Write Your Own Review
Capacity
| Ajax devices |
up to 100 Specifically:
|
| Users |
up to 50
|
| Automation scenarios |
up to 32
|
| Security groups |
up to 9 |
| Rooms | up to 50 |
| Event Log |
up to 1,000 events Events are saved in the non-volatile onboard flash memory. |
Wireless Communication
| Jeweller communication technology |
Proprietary wireless communication technology to transmit commands, alarms, and events. Key features:
|
| Frequency bands |
866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz Depends on the sales region. |
| Maximum effective radiated power (ERP) |
up to 25 mW Automatic power control to reduce power consumption and radio interference. |
| Radio signal modulation | GFSK |
| Radio communication range |
up to 2,000 m Between the hub and the devices added to it in open space. The maximum range depends on the added device. |
| Polling interval |
from 12 s to 300 s Adjusted by a PRO or user with admin rights in Ajax apps. |
| Encrypted communication |
All stored and transmitted data are protected by block encryption featuring a dynamic key. |
| Wings communication technology |
Proprietary wireless communication technology to transmit photos. Key features:
|
| Frequency bands |
866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz Depends on the sales region. |
| Maximum effective radiated power (ERP) |
up to 25 mW Automatic power control to reduce power consumption and radio interference. |
| Radio communication range |
up to 2,000 m Between a hub and connected devices (in an open space). The maximum range depends on the connected device. |
| Encrypted communication |
All stored and transmitted data are protected by block encryption featuring a dynamic key. |
| Frequency hopping |
To prevent radio interference and jamming. |
Communication channels
| Cellular |
2 × micro SIM slot |
| Cellular bands |
2G GSM900/DCS1800 (B3/B8) 3G WCDMA 850/900/2100 (B1/B5/B8) 4G (LTE) FDD B1/B3/B5/B7/B8/B20 |
| Automatic switching between communication channels |
between SIM cards — up to 4 minutes |
| Communication channel prioritization |
|
| Auto APN | The APN auto select feature allows setting the access point automatically based on the installed SIM card. |
| External antenna connectors |
Jeweller Wings 4G (LTE) The system will notify users if the antenna is damaged. ExternalAntenna is sold separately. |
| Alarm transmission system category | SP5 |
| Control panel operation method |
pass-through |
| Signaling security |
S2 Substitution security. |
| Information security | I2 |
Notifications
| Notification types |
|
| Event types |
Notification types are configured individually for each user. The notifications can be customized for A–D schemes according to EN 50131 requirements. |
Monitoring
| Supported protocols |
|
| Event types |
|
Photo Verification
| Photo verification types |
The Photo by schedule feature is available for hubs with OS Malevich 2.19 firmware or later. |
| Photo delivery time |
up to 9 s |
| Photo resolution |
up to 960 × 720 pixels Depends on the detector. |
| Number of photos in a series | from 1 to 5 |
Autonomous Operation
| On an external battery in full function mode |
up to 18 months On a 12 V⎓, 600 Ah, non-rechargeable zinc-air external battery (not included). |
| On an external battery in Battery saving mode |
more than 5 years On a 12 V⎓, 600 Ah, non-rechargeable zinc-air external battery (not included). |
| On an internal battery in Battery saving mode |
up to 23 months On a 7.2 V⎓, 95 Ah, non-rechargeable LTC Internal battery NB (7.2V/95Ah) (not included). up to 8 months On a 6.4 V⎓, 36 Ah, rechargeable LiFePO4 Internal battery RB (6.4V/36Ah) (not included). up to 2 months On a 12 V⎓, 7 Ah, rechargeable lead-acid internal battery (not included).
|
Sabotage Protection
| Tamper alarm |
The system sends notifications of attempts to open the hub casing lid or detach the casing from the surface. |
| Protection against spoofing |
device authentication |
| Frequency hopping |
The hub sends notifications of jamming or connection loss with the devices to all users and the monitoring company. |
| Jamming alert | Hub BP Jeweller analyzes the noise level in the channel and the communication quality with the added devices and sends a notification in 30 seconds. |
Power supply
| External |
4.2–16 V⎓, up to 2 A Zinc-air battery or external power source. |
| Internal |
4.2–16 V⎓, up to 2 A Rechargeable lead-acid and LiFePO4 batteries (not included). Non-rechargeable LTC batteries (not included). |
| Device operating DC voltage range | 3.5–16 V= |
Enclosure
| Dimensions |
196 × 238 × 100 mm |
| Weight |
1.01 kg |
| Operating temperature range |
from −10 °C to +40 °C |
| Operating humidity |
up to 75% |
| Protection class | IP40 |
Colour
| Available colours | Black, White |
Complete Set
| Contains |
Hub BP Jeweller Casing Installation kit Quick start guide |
Warranty
| Warranty Period | 24 months |
