In stock
Product Code
XL32-24
SKU
HA8024
Haes Esento Evoque 24 Zone Conventional Control Panel
Esento Evoque 24 Zone Conventional Control Panel
DELIVERY
We always aim to same day dispatch on all orders received before 2.30pm.
TRADE COUNTER
Firesense also offer the ability to collect your order from our trade counter.
24 Zone Esento Evoque fire alarm control panel. Evoque panels are Haes' large zone format range and provide a generous selection of programmable features, inputs and outputs. Fully networkable up to 8 control panels, 3 false alarm management modes and fully functional repeater panels. (N.B No Twin Wire mode)
24 Zone Esento Evoque fire alarm control panel. Evoque panels are Haes' large zone format range and provide a generous selection of programmable features, inputs and outputs. Fully networkable up to 8 control panels, 3 false alarm management modes and fully functional repeater panels. (N.B No Twin Wire mode)
| Category Type | Panel |
|---|---|
| Colour | Grey |
| IP Rating | IP30 |
| System Type | Conventional |
| Clearance | No |
Write Your Own Review
Enclosure
Cable Entry
Dimensions
Mains Supply
Battery Capacity
Detection Zones
Sounder Circuits
Networking
On Board Relays
Programmable Outputs
Swith Inputs
Event Log
Intrinsically Safe Mode
False Alarm Management
Delay Timer
1.2mm Mild Steel IP30. Colour ref: MW334E Interpon powder coat
Via 20mm knockouts located in the top and rear of the cabinet
Back box: 450mm W x 400mmH x 130mm D, Lid: 465mm W x 410mm H x 25mm D
5A internal switch mode power supply, Nom 27v DC
2 x 18Ah 12V VRSLA
24 x conventional. EOL = 4K7
4 x monitored, fused @500mA. EOL = 4K7
Up to 8 control panels, fault tolerant RS485 communication, requires TPCA05 network card
2 x programmable, 3A, 30V volt free changeover
4 x programmable 40mA switch -ve outputs
Class change, alert (pulsing), silence alarms & reset
40 event history
Selectable per zone
Type A, B & C dependency modes, approved by LPCB
On board programmable delay timer 1-10 mins
